Product Details
Clean Laminar Flow Hood
Professional air purification units designed for local clean environments. Featuring SUS304 stainless steel construction and vertical unidirectional flow to ensure maximum process area cleanliness.
Inquiry Now ✉
Introduction Detail
Purified laminar flow cover is an air purification unit that provides a local clean environment. It can be flexibly installed above the process point where high cleanliness is required. It can be used alone or in combination to form a strip-shaped clean area. Purified laminar flow cover passes the air through a high-efficiency filter at a certain wind speed to form a uniform flow layer, so that the clean air is vertically unidirectional, thereby ensuring the cleanliness of the process area.
Key Features
- ✅ Quality Build: Cabinet made of high quality SUS304 stainless steel, which is easy to clean.
- ✅ High Efficiency: Top air supply with filter efficiency ≥99.99% @ 0.3um.
- ✅ Smart Control: Inverter adjusts wind speed; button controls for lighting and power.
- ✅ Superior Cleanliness: Operating area purification level is higher than room cleanliness.
Technical Specifications
| Material | High Quality SUS304 Stainless Steel Panel |
| Installation Type | Hanging type / Landing support type |
| Average Wind Speed | 0.25 - 0.45m/s (Adjustable via Inverter) |
| Filter Efficiency | ≥99.99% @ 0.3um |
| Noise Level | ≤ 62dB(A) |
| Power Supply | 220V / 50HZ |
| Usage | Local Air Purification |
| Applications | Electronics, Pharmaceuticals, Food, Machinery, Fine Chemicals |
| Certification | ISO9001:2008; SGS |
Detailed FAQ
How does the laminar flow cover maintain the vertical unidirectional flow?
The unit passes air through a top-mounted high-efficiency filter at a controlled wind speed. This process forms a uniform, strip-shaped flow layer, ensuring clean air moves vertically to protect sensitive process points.
What makes SUS304 stainless steel the preferred choice for the cabinet?
SUS304 stainless steel is chosen for its exceptional durability and hygiene properties. It is highly resistant to corrosion and extremely easy to clean, meeting strict pharmaceutical and food safety standards.
Can this unit be integrated into existing clean room structures?
Yes, it is designed for maximum flexibility. It can be installed as a hanging unit directly over process points or as a landing support type, used either alone or in combination to suit various facility layouts.
